DESCRIPTION
Part 1: Machine requirements as follows:
1. The maximum sealing width 450mm.
2. The machine height from the ground is about 750mm.
3. The maximum height of the bag is 500-550mm.
4. Bag material is PE.
5. Conveyor belt is long enough to be suitable for worker to collect the finished bags.
6. Equipped with oil cylinders to keep enough pressure and make the sealing straight.
7. Automatic left and right movement of the sealing device.
8. Pushing area(distance) is 200mm. Pushing plate height is 400mm.
Part 2. Machine electrical parts listed as below：
| Name | Usage | Model No | Brand | Quant |
| 2P Leakage Protection Circuit Breaker | Protection Electrical Appliance | DZ47-63-C20 | Chint | 1 |
| Intermediate relay | Transit | JZX-22F(D)/2Z | Omron | 5 |
| Time Relay | Timing seal | AH2-Y | Omron | 2 |
| Conveying motor | Conveyor belt operation | 4RK25GN-c | Maili | 1 |
| Stimulation transformer | Sealing | BK-800-220V | Xunda | 1 |
| Water cooling pump | Water-cooled sealing strip | 1 | ||
| solid state relay | Transit | TRA-23D80MI | LIDE | 1 |
| Photoelectric switch | E3JK-TR12-C | Omron | 2 | |
| Magnetic switch | Airtac | 4 | ||
| Oil pump motor | 2P-1.5KW | 1 |
Hot selling countries: Impulse sealing machine is well sold in Mexico, Brazil, Japan, Russia, India etc.
